YT40DC12 Varilight 230V AC to 12V DC Dimmable Converter for LED Strip, LED Strip Max 40 Watts

Varilight Dimmable power supply for 230V AC to 12V d.c LED strip up to a maximum of 40W

..................................................
This is a quality VARILIGHT Dimmable Converter that was launched to provide a trouble-free solution for dimming up to 40 watt LED Strip, and can be used in conjunction with any of the V-Pro Dimmers which uses a soft start technology that extends lamp life and product life.

..................................................
The Varilight Dimmable Converter, like all our products, is designed to meet the latest European Safety Legislation.

..................................................
VARILIGHT Dimmable Converters' reputation for reliability and ease of installation has grown to such an extent that they have become the preferred choice for many electricians whether or not they are to be dimmed.

..................................................
To bring an end to the uncertainty of compatibility VARILIGHT have developed this top-quality Dimmable Converter at a realistic price.

..................................................

Appearance, Function and Applications

These Dimmable Converter have innovative features:
Soft Start Technology, which gently brings lights up to full brightness when you switch on and this extends lamp life
It is possible to power several lengths from one AC/DC transformer as long as the total load is less than the maximum rating by connecting the LED strips in parallel
Refer to the maximum load information for low voltage transformers provided with the dimmer to determine the maximum permitted load (measured by the total wattage of transformers to be connected) and, in any case, do not exceed 250W per dimmer circuit
Enhanced performance with all 12V LED lamps up to a maximum of 30W
Dimmable power supply for 12V d.c LED strip up to a maximum of 40W
Auto-resetting overload protection and over-temperature
Short circuit protection
Designed in consultation with electricians for ease of cable termination and fitting

When powering LED Strips
Dimmable power supply for 12V d.c LED strip up to a maximum of 40W.

When powering LED Lamps
Dimmable power supply for 12V d.c LED strip up to a maximum of 40W

..................................................
-Height (mm): 23

-Width(mm): 54

-Length (mm): 167

Limitations

IMPORTANT: Always turn off the electricity supply at the mains before beginning any electrical work.
VARILIGHT AC/DC transformers are suitable for indoor use only.
Install in a well-ventilated location, away from heat sources (the maximum operating temperature is 40�C).
Do not connect the output cables of one Dimmable Converter to those of another.
Observe the correct DC polarity when connecting the LED load.
To achieve even light levels use identical lengths of LED strip on the output side of the AC/DC Converter(s).
The light switch or dimmer switch should be located on the primary (input) side of the transformer.
If many bulbs are being controlled from one transformer, use a terminal block to distribute the wiring.
If you require a longer cable than supplied then use a proprietary terminal block to connect a suitable additional cable (min 2 x1.0mm2, ensuring no bare wires protrude from the terminals and keeping the length of additional wiring to a minimum).

..................................................

Product Instructions & Manuals

-YTDC005_VARILIGHT_ACDC_Converter_System_Instructions PDF-
