MIP1000 Varilight V-Plus Series 200-1000 Watt/VA Dimmer Module

Varilight MIP1000 (Z0IP1000) V-Plus Series 1 or 2 Way 200-1000 Watt Intelligent Dimmer Module kit (Included with the module is a nut and also wiring instructions), It is ideal for dimming mains and almost all Low Voltage applications, and is especially suited for up to 1000 Watts of Halogen or GLS Lighting, but these dimmers will NOT dim LEDs.

For a selection of different colour Dimmer Knobs and extra components please look in our Additional Extras Category.

..................................................
VARILIGHT Dimmer Switches have an industry-wide reputation for exceptional performance, long life and innovation at attractive prices.
..................................................
The VARILIGHT V-Plus Series Dimmer, like all our products, is designed to meet the latest European Safety Legislation.
..................................................
It is important to select the correct dimmer switch for your application, so please read the following information carefully, if need be look at PDF manuals, and if you are still unsure, then contact us.
..................................................

Appearance, Function and Applications

This dimmer is push on/off and rotary controlled, meaning to turn the dimmer on or off simply push the dimmer spindle in and it will click back out; then to turn the brightness up or down, rotate the spindle clockwise and anti-clockwise.
..................................................
V-Plus Push on/off dimmers are suitable for either 1 way or 2 way circuits.
..................................................
V-Plus Series Dimmers are Leading Edge and can be used with mains voltage lighting and good quality Low Voltage Electronic Transformers.
..................................................
The V-Plus Series Push on/off Dimmers can be used for mains incandescent GLS lamps (standard mains light bulbs), up to the maximum load as specified on the dimmer.
..................................................
The V-Plus Series can also dim GU10 or similar Hi Spot Mains Halogen lamps (only use quality UK supplied lamps) up to the maximum load as shown in the PDF instruction manual.
..................................................
When using Electronic Low Voltage Transformers we recommend that a maximum of 5 good quality dimmable Electronic Transformers are used (10 if Varilight Transformers) with this dimmer range. Please note: add the watts of the bulbs/lamps if using Varilight Transformers, to determine which wattage of dimmer to select, but if using another manufacturer of Transformer, add up the VA of the Transformers so it does not exceed the maximum of the dimmer. Please note that noise levels can depend on the quality of the Transformer being used.
..................................................
The V-Plus Series Push on/off Dimmers can be used in 2 way circuits (where one lighting circuit is controlled from two locations). In order to achieve 2 way switching, they must be paired with a standard 2 way switch in the other location.

3-way switching can be achieved by adding an intermediate switch in to the circuit. When using V-Plus Series Push on/off Dimmers in a 2 or 3 way circuit the lights can only be dimmed from the location that the dimmer is situated in, if total dimming is preferred from many switched locations, in a 2, 3 or more way circuit then choose the Varilight Touch and Remote range of dimmers, in conjunction with Slave Dimmers.
..................................................
The V-Plus Series are equipped with some intelligent features: Soft-Start Technology, allows a longer life span of the bulbs or lamps used by increasing the brightness level softly, which also creates a welcoming effect; Self Re-setting Overload Protection, so is able to handle overload situations, for example, if the wattage of the bulbs/lamps are accidentally too high on a circuit. This is achieved by either, stepping down the dimmer's output to the lamps (if the watts are marginally overloaded), or the dimmer cuts out before there is any damage, (if the watts are grossly overloaded), until the load is reduced; Intelligent Heat Sensor which again stops damage to the dimmer, if it becomes too hot.
..................................................

Limitations

These dimmers will NOT dim LEDs, if dimming LEDs choose either the V-Pro, Multi-Point Remote, Multi-Point Touch, or V-Com Dimmer Series.
Do not use this dimmerswitch for fluorescent bulbs, energy saving bulbs or fans. The dimmerswitch will eventually be damaged beyond repair if used for these applications. Incorrect use will make your guarantee invalid.
..................................................
Varilight Dimmers can NOT be used for wire-wound or torroidal Transformers. For Fan applications choose V-Dim Solid State Series, please check with manufacturer of appliance to be dimmed.
..................................................

Product Instructions & Manuals


- Intelligent Dimmer Instructions PDF
- V-Plus Dimmer Series Compatibility Guide PDF
- Compatibility Detailed PDF
- Compatibility Overview PDF
