MH0 Varilight non-dimming 'Dummy' Series switch module 0-1000 Watt

#MH0
GTIN: 5021575193305

£4.74 £3.95
MH0 [Z0H0-P] Varilight Non-dimming 'Dummy' Series module, 1 or 2 Way Up To 0-1000 Watt Switch Module for retro fitting or adding to The Matrix. This small module fits on to 1, 2, 3, and 4 Gang Matrix plates

✔ This is NON-DIMMING, and works like a rocker switch, Push On/Off
✔ Suitable for either 1 way or 2 way circuits
✔ Max Load 1000 Watt for any type or amount of bulbs or lamps
✔ Min Load 0 Watt
✔ Looks like a dimmer but on/off function only
✔ Easy Fit Module Replacement Kit
✔ To replace dimmer modules in an already existing product or The Matrix
Availability: In stock
SKU
MH0
Varilight MH0 (Z0H0) Dummy Dimmer Push on/off Series 1 or 2 Way, 6 Amp, 0-1000 Watt non-dimming Module Kit (Included with the module is a nut and also wiring instructions).

For a selection of different colour Dimmer Knobs and extra components please look in our Additional Extras Category.

..................................................
VARILIGHT Dimmer Switches have an industry-wide reputation for exceptional performance, long life and innovation at attractive prices.
..................................................
The VARILIGHT Dummy Series, like all our products, is designed to meet the latest European Safety Legislation.
..................................................
It is important to select the correct dimmer switch for your application, so please read the following information carefully, if need be look at PDF manuals, and if you are still unsure, then contact us.
..................................................

Appearance, Function and Applications

This 'Dummy' is push on/off, meaning to turn the dimmer on or off simply push the spindle in and it will click back out.
..................................................
This dummy dimmer is a non-dimming solution for products, e.g. outdoor security lights, that can not be dimmed.
..................................................
The beauty of this Dummy Series is that it is identical in appearance to a dimmer switch but without the dimming function.
..................................................

Product Instructions & Manuals


- Wiring Accessories PDF
- Compatibility Detailed PDF
- Compatibility Overview PDF
More Information
Product Filters Matrix Modules
Switch Type Dummy Dimmers, 10 Amp - Light Switch
Switch Gangs 1 Gang Switch
Dimmer Features Dummy
Dimmer Circuits 2 Way
Write Your Own Review
You're reviewing:MH0 Varilight non-dimming 'Dummy' Series switch module 0-1000 Watt

Product Features


✔ This is NON-DIMMING, and works like a rocker switch, Push On/Off
✔ Suitable for either 1 way or 2 way circuits
✔ Max Load 1000 Watt for any type or amount of bulbs or lamps
✔ Min Load 0 Watt
✔ Looks like a dimmer but on/off function only
✔ Easy Fit Module Replacement Kit
✔ To replace dimmer modules in an already existing product or The Matrix
..................................................

Range: Module

Product Category: Matrix Modules

Dimensions: 50x26x42mm

Product Weight: 60g

Recommended Back Box Depth: 25mm (Classic), 35mm (Screwless & Ultra)

Operating Voltage: 220/250V AC

Maximum Load Rating: 6A

Maximum Current Rating: 6A

Terminal (Live) Diameter: 3.2mm; Capacity: 3 x 1.5mm²


..................................................

Intended Applications: Indoor Use Only. Domestic lighting circuits.

Safety Advice: No dimming function. Product Must Be Earthed.

Applicable Safety Standard: BS EN 60669-2-1
