MFP1M1 Varilight Special Series for Multiple HF Dimmable Ballasts and LED Drivers 1-10V DC Input, 6 Amp Max Dimmer Module

Varilight MFP1M1 (Z0FP1M1) F-Series Single 1 or 2 Way Dimmer Module Kit (Included with the module is a nut and also wiring instructions), Designed for one or more High Frequency Dimmable Ballasts/LED drivers that Require a 0-10V (or 1-10V DC) Control Signal up to 20 mA, module only.

For a selection of different colour Dimmer Knobs and extra components please look in our Additional Extras Category.
..................................................

VARILIGHT Dimmer Modules have an industry-wide reputation for exceptional performance, long life and innovation at attractive prices
..................................................
The VARILIGHT Special F-Series Dimmer Module, like all our products, is designed to meet the latest European Safety Legislation
..................................................
It is important to select the correct dimmer module for your application, so please read the following information carefully, if need be look at PDF manuals, and if you are still unsure, then contact us
..................................................
This dimmer module is push on/off and rotary controlled, meaning to turn the dimmer on or off simply push the spindle in and it will click back out; then to turn the brightness up or down, rotate the spindle clockwise and anti-clockwise
..................................................
Varilight Special Series Dimming function is virtually the same as 0-10V. The difference is that VARILIGHT 1-10V dimmers are 1 or 2 way and can be controlled in a 2 way setup with a standard switch. They also have a push on/off action to turn off the mains (0V position) whereas 0-10V will just turn down to a '0' position
..................................................
These types of dimmers require an extra two cores of cable as the dimming and switching functions are separate. The switching side is wired as a conventional switch to the mains and the dimming side is connected via the extra two core cable to the positive and negative terminals on the dimmable ballast/LED driver. Please see the wiring diagram on the instructions leaflet PDF for more information
..................................................
Do not use this dimmer module for any other purpose or connect this dimmer to the mains, as your guarantee will be invalid
..................................................
Please see recommendation of maximum loads in the Compatibility Detailed PDF
..................................................
WARNING:The switch in this product is rated at 6 Amps MAX. Check the in-rush current for LED bulbs or drivers before connecting. Fit inrush current limiters where necessary
..................................................
Product Instructions & Manuals


- Ballast Dimmer PDF
- 1-10VDiagram PDF
- Compatibility Detailed PDF
- Compatibility Overview PDF
